Adagio™ Balanced Audio Receiver Crestron ABAR-1
2 • Adagio™ Balanced Audio Receiver: ABAR-1 Operations Guide – DOC. 6549A
Applications
The following diagram shows an ABAR-1in a residential application.
ABAR-1 in a Residential Application
Specifications
Specifications for the ABAR-1 are listed in the following table.
ABAR-1 Specifications
SPECIFICATION DETAILS
Audio
Frequency Response
S/N Ratio
THD+N
20Hz – 20kHz, ± 0.3 dB
95 dB, 20Hz to 20kHz A-weighted
0.008%, 20Hz to 20kHz
Power Requirements
12VDC
Power Supply (included)
6 Watts (0.5 Amps) @ 12 VDC
120 VAC, 60 Hz (ABAR-1)
230 VAC, 50 Hz (ABARI-1)
Environmental
Temperature 41º to 104ºF (5º to 40ºC)
Humidity 10% to 90% RH (non-condensing)
Enclosure Black metal, surface mount box
with (2) integral mounting flanges
Dimensions
Height
Width
Depth
0.96 in (2.43 cm)
2.73 in (6.93 cm)
3.19 in (8.11 cm)
Weight 4.0 oz (114 g)
