50XP
Performance data-
Standard ECM Indoor Motor
COOLING CAPACITIES
See Legend and Notes on page 13.
50XP024 COOLING PERFORMANCE TABLE
Temp (F)
Outdoor Air
Entering
Condenser
Evaporator Air—CFM/BF
800/0.026
900/0.032
1000/0.04
Evaporator Air — Ewb (F)
62
63*
67
72
62
63*
67
72
62
63*
67
72
75
TC
SHC
kW
24.0
24.5
26.5
29.1
24.6
25.1
27.1
29.8
25.1
25.5
27.4
30.4
21.9
21.3
18.7
15.4
23.5
22.8
19.8
16.1
25.0
24.2
20.8
16.7
1.7
1.7
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.9
85
TC
SHC
kW
22.9
23.3
25.3
27.9
23.5
23.9
25.8
28.5
23.9
24.3
26.2
28.9
21.4
20.7
18.1
14.9
22.9
22.2
19.2
15.6
24.3
23.6
20.3
16.2
1.9
1.9
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.1
2.1
95
TC
SHC
kW
21.8
22.2
24.0
26.5
22.3
22.6
24.5
27.0
22.7
23.0
24.8
27.4
20.8
20.2
17.6
14.3
22.3
21.6
18.7
15.0
23.6
22.9
19.7
15.6
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.3
2.3
105
TC
SHC
kW
20.5
20.9
22.6
25.0
21.0
21.3
23.0
25.4
21.6
21.7
23.3
25.7
20.2
19.5
16.9
13.7
21.6
20.9
18.0
14.3
22.5
22.2
19.0
14.9
2.4
2.4
2.4
2.4
2.4
2.4
2.5
2.5
2.5
2.5
2.5
2.5
115
TC
SHC
kW
19.2
19.5
21.1
23.3
19.8
19.9
21.5
23.7
20.7
20.4
21.7
23.6
19.4
18.8
16.3
13.0
20.6
20.2
17.3
13.7
21.5
21.2
18.3
14.1
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.8
2.8
125
TC
SHC
kW
17.8
18.0
19.4
21.4
18.5
18.5
19.5
21.7
19.0
19.0
19.9
21.9
18.5
18.1
15.5
12.3
19.2
19.2
16.5
12.9
19.8
19.7
17.6
13.5
2.9
2.9
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.1
3.1
50XP030 COOLING PERFORMANCE TABLE
Temp (F)
Outdoor Air
Entering
Condenser
Evaporator Air—CFM/BF
875/0.06
1000/0.07
1125/0.08
Evaporator Air — Ewb (F)
62
63*
67
72
62
63*
67
72
62
63*
67
72
75
TC
27.9
28.6
30.7
33.6
28.8
29.4
31.6
34.5
29.3
30.0
32.2
35.2
SHC
24.1
20.0
20.6
16.8
26.0
21.2
22.1
17.8
27.0
22.6
23.5
18.7
kW
2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.2
2.1
2.1
2.1
2.2
85
TC
26.9
27.5
29.5
32.3
27.6
28.1
30.2
33.1
28.3
28.7
30.8
33.7
SHC
23.8
19.5
20.3
16.4
25.6
20.8
21.7
17.4
26.5
22.1
23.1
18.3
kW
2.3
2.3
2.4
2.4
2.3
2.4
2.4
2.4
2.4
2.4
2.4
2.4
95
TC
25.6
26.2
28.2
30.8
26.3
26.8
28.8
31.5
27.0
27.3
29.3
32.0
SHC
23.1
19.1
19.9
16.0
24.7
20.5
21.3
16.9
26.2
21.7
22.6
17.8
kW
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
105
TC
24.3
24.7
26.6
29.2
25.1
25.3
27.2
29.7
25.9
25.7
27.5
30.1
SHC
22.4
18.6
19.3
15.4
23.8
19.9
20.8
16.3
24.4
21.1
22.1
17.2
kW
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
115
TC
22.8
23.2
24.9
27.3
23.8
23.6
25.3
27.7
24.5
24.0
25.7
28.1
SHC
21.7
18.0
18.8
14.8
22.3
19.3
20.2
15.7
23.7
20.5
21.5
16.6
kW
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
125
TC
21.4
21.4
24.9
27.3
23.8
23.6
25.3
27.7
24.5
24.0
25.7
28.1
SHC
20.7
17.3
18.8
14.8
22.3
19.3
20.2
15.7
23.7
20.5
21.5
16.6
kW
3.5
3.5
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
