8 MEASUREMENT
S
-20
-40
-60
-80
-00
-20
dB
00u 200u 500u m 2m 5m 0m 20m 50m 00m 200m 500m 2 5
Vrms
-20
-30
-40
-50
-60
-70
-80
-90
-00
dB
00u 200u 500u m 2m 5m 0m 20m 50m 00m 200m 500m 2 5
Vrms
USER MANUAL
VORTEX 3 QUADRO P.34
Figure 8.9
CCIF difference frequency method (0,5 kHz und ,5 kHz) @ 8 Ω
vs. input level (Measurements of a typical performance)
Figure 8.0
SMPTE Intermodulation distortion (60 Hz und 7 kHz) @ 8 Ω
vs. input level (Measurements of a typical performance)
— Channel A
— Channel B
— Channel C
— Channel D
