7 SPECIFIC
ATION
USER MANUAL
VORTEX 3 QUADRO P.30
Output Power
kHz, THD < 0, % , in mono-bridge mode 2 x 500 W @ 8 Ω
2 x 900 W @ 6 Ω
kHz, THD < 0, %, in parallel-mono mode 2 x 500 W @ 2 Ω
2 x 900 W @ 4 Ω
kHz, THD < %, all channels driven
Duration limited by fuse / thermal protection for RL < 8 Ω
in stereo mode or RL < 6 Ω in mono-bridge mode.
Measurement at 2 Ω without preconditioning (EN 60268-3)
4 x 750 W @ 4 Ω
4 x 450 W @ 8 Ω
Circuitry Bipolar, Class H 2-step
high efficiency circuit
Signal to Noise-Ratio
20 Hz - 20 kHz, 8 Ω, unweighted
A-weighted
>03 dB
>06 dB
Power Consumption @ 230 V
(all channels driven)
Typical ) Max 2)
Idle ,4 A
67 W
6 Ω 3,9 A
385 W
0, A
490 W
8 Ω 5,6 A
638 W
7, A
2650 W
4 Ω 7,8 A
070 W
28, A
4440 W
Multiply currents by 2 for 20 V
) /8 of max Output Power with pink noise to represent typical music signal
2) max. rated Output Power (see above)
