Quick Start Guide
SXG cameras with Kodak sensors
Product Specification
SXG cameras – Maximum Performance with Kodak sensors
Dual Gigabit Ethernet progressive scan CCD camera
▪
Compact and lightweight aluminium housing
▪
Power over Ethernet support
▪
Standard RJ45 connector
▪
GigE Vision
▪
TM
standard compliant
Excellent image quality at high image rates
▪
Resolutions of 1, 2, 4 or 8 megapixel
▪
Frame rates up to 120 fps
▪
Compact design (52 x 52 x 72 mm)
▪
Camera Type
Sensor
Size
Resolution
Full Frames
[max. fps]
Monochrome
SXG10
1/2"
1024 x 1024
120
SXG20
2/3"
1600 x 1200
68
SXG21
2/3”
1920 x 1080
64
SXG40
1”
2336 x 1752
32
SXG80
4/3”
3296 x 2472
16
Color
SXG10c
1/2”
1024 x 1024
120
SXG20c
2/3”
1600 x 1200
68
SXG21c
2/3”
1920 x 1080
64
SXG40c
1”
2336 x 1752
32
SXG80c
4/3”
3296 x 2472
16
Installation
open wire
Installation sample without PoE
1 - network interface card
2 - network cable
3 - Process interface cable
4 - Power cable
Dimensions
(11047092)
● SXG-F (F-Mount version)
26
36
26
36
16 x M3 depth 6
UNC 1/4-20
52
52
26
36
72
Dimensions
(11047091)
● SXG (C-Mount version)
26
36
26
36
16 x M3 depth 6
UNC 1/4-20
52
52
26
36
72
open wire
open wire
open wire
open wire
5
4
Installation sample with PoE via NIC
1 - PoE network interface card (NIC)
2 - network cable
3 - Process interface cable
Notice
Operation with a single GigE link is
possible as well.
Installation sample with PoE via Injector
1 - network interface card (NIC)
2 - network cable
3 - Injector
4 - network cable
5 - Process interface cable
Latest software version and technical
documentation are available at:
