Chrysler 2005 300 SRT8 User Manual
Page 267
Cavity
Fuse
Circuits
4
40 Amp Green
Battery
5
30 Amp Pink
Heated Seat/Steering
Column
6
20 Amp Yellow Fuel Pump
7
—
—
8
15 Amp Dk.
Blue
Ignition Start/Run - Start
9
20 Amp Yellow Console Power Outlet
10
10 Amp Red
Rear Fog Lamp — If
Equipped
11
25 Amp
C/BRKR
Memory Module/Door
Locks
12
25 Amp
C/BRKR
Passenger Power Seat
13
30 Amp
C/BRKR
Door Module Run/Acc/
Delay
14
10 Amp Red
Sentry Key/Remote Key-
less Entry/Cluster
15
—
—
16
—
—
17
—
—
Cavity
Fuse
Circuits
18
20 Amp Yellow Selectable Power Outlet
19
10 Amp Red
Stop Lamp
20
—
—
21
—
—
22
—
—
23
—
—
24
—
—
25
—
—
26
—
—
27
10 Amp Red
Airbag/Occupant Classi-
fication Module
28
10 Amp Red
Curtain Airbag - if
equipped
29
5 Amp Orange Sentry Key/Remote Key-
less Entry/Powertrain
Control Module Ignition
Feed
30
10 Amp Red
Steering Column
Module/Power Mirrors
31
—
—
MAINTAINING YOUR VEHICLE
267
7
