Item # DT2-030AR, DT2-030AR Digital Torque Wrench
QUOTE
DT2-030AR Digital Torque Wrench
• Unit Selector: kgf.cm, N.m, inf.in, ftf.in, lbf.ft
• Functions: Torque, Unit and Mode settings
• Torque range 13.2 to 265.2 lbf.in (1.5 to 30 N.m)
• 1/4 in. square drive
• Lever type ratchet
• Data storage, clear, output and on-line calibration
• Audible beep and visible LED display with Red/Green indicator lights
• Memory 250 data points
• AA Battery operation, (2) included as standard
· SPECIFICATIONS · CLASSIFICATION
SPECIFICATIONS
Model No.
DT2-030AR
Drive Size
1/4 in. square
Head Type
Lever Type Ratchet
Gear/Teeth
36
Torque
1.5 to 30 N·m
1.1 to 22.1 lbf·ft
Accuracy CCW
+/- 2 %
Accuracy CW
+/- 1 %
Length
15.35 in
390 mm
Power
AA Battery
