Item # ASG-EH2-R1016-S, ASG-EH2-R1016-S Lever Start Transducerized Electric Screwdriver with
Spline
QUOTE
ASG-EH2-R1016-S Lever Start Transducerized Electric Screwdriver with
Spline
ASG-EH2-R1016-S Lever Start Transducerized Electric Screwdriver with Spline is a premium, robust tool featuring
ergonomic comfort grip and Pulse Fastening Technology, which reduces the reaction typically associated with high torque
tools.
• Inline body style with 3/8" Square drive and Lever Start operation
• Max. torque 141.6 lbf.in | 11.8 lbf.ft | 16 N.m
• Transducerized DC electric torque and angle control with brushless motor
• Sleek profile aluminum body
· SPECIFICATIONS · CLASSIFICATION · FOR USE WITH: · WARRANTY
SPECIFICATIONS
Model No.
ASG-EH2-R1016-S
Drive Size
3/8 in. square
Driver Type
Inline with Spline
Operation
Lever Start
Torque
3.2 to 16 N·m
28.3 to 141.6 lbf·in
Max. RPM
1247 rpm
Length
13.5 in
344 mm
Weight
2.9 lb
1.3 kg
CLASSIFICATION
