Item # 65277, ASG DTW Series TAW400-W Wireless Digital Torque Wrench with Torque and Angle
Measurement
QUOTE
ASG DTW Series TAW400-W Wireless Digital Torque Wrench with Torque and
Angle Measurement
DTW Series Digital Torque wrenches hold up in any environment. Features a robust bi-directional ratchet head and
ergonomic soft grip no-slip handle to ensure user comfort. TAW-W wrenches measure torque and angle, and are
equipped with wireless technology. Features a user-friendly multiple mode menu-driven platform with Date, Track, Peak,
Set, Recall, Upload, Languages and Comms menu functions. Displays in multiple languages. Viewing angle of 170
degrees. Accuracy +/- 1% of actual reading from 10% to 100% of full scale.
• Gold standard quality design, components and accuracy
• Compatible with WCBR Wireless Smart Receiver Box (purchased separately)
• Unit Selector: cN.m, N.m, kgf.cm, kgf.m, in.oz, lbf.in, lbf.ft
• 99 programmable presets with 2,000+ onboard measurement memory
• Calibration by date or number of cycles
• PC software (Windows Excel, SPC output)
• PLC communications with ASCII or binary
• Torque range 29.5 to 295 lbf.ft (40 to 400 N.m)
• 1/2" square drive
• High visibility full color organic LED display screen with color indicator LED lights along with audible alarm
• Operates and reads CW and CCW
• AA Battery operation with up to 180 hours of battery life. (Battery life reduces to minimum 40 hours of continuous use
when optional wireless transmission and Angle modes are in operation.)
· SPECIFICATIONS · CLASSIFICATION · FOR USE WITH:
SPECIFICATIONS
Model No.
TAW400-W
Drive Size
1/2 in. square
Head Type
Ratchet
Torque
40 to 400 N·m
29.5 to 295 lbf·ft
Accuracy CW
+/- 1 %
Accuracy CCW
+/- 1 %
Length
24.6 in
625 mm
