Cavity Cartridge

Fuse

Mini-

Fuse

Description

9

—

—

—

10

30 Amp

Pink

—

Windshield Wiper

11

30 Amp

Pink

—

Anti-Lock Brake

System (ABS) Valves

12

40 Amp

Green

—

Radiator Fan

Lo/High

13

50 Amp

Red

—

Anti-Lock Brake

System (ABS)

Pump Motor

14

—

—

Spare

Cavity Cartridge

Fuse

Mini-

Fuse

Description

15

50 Amp

Red

—

Radiator Fan Motor

16

—

—

—

17

—

—

—

18

—

—

—

19

—

—

—

20

—

—

—

21

—

—

—

22

—

—

—

7

MAINTAINING YOUR VEHICLE 401
