Cavity

Car-
tridge
Fuse

Mini-
Fuse

Description

9

—

—

—

10

30 Amp
Pink

—

Windshield Wiper

11

30 Amp
Pink

—

Anti-Lock Brake System
(ABS) Valves

12

40 Amp
Green

—

Radiator Fan Lo/High

13

50 Amp
Red

—

Anti-Lock Brake System
(ABS) Pump Motor

14

—

—

—

15

50 Amp
Red

—

Radiator Fan

Cavity

Car-
tridge
Fuse

Mini-
Fuse

Description

16

—

—

—

17

—

—

—

18

—

—

—

19

—

—

—

20

—

—

—

21

—

—

—

22

—

—

—

376

MAINTAINING YOUR VEHICLE
