K Series Power Amplifiers
page 14 Operation Manual
Minimum Guaranteed Power K1 K2
120 VAC, 60 Hz Units, Stereo mode, per channel, both channels driven
1 kHz with 0.1% THD
Stereo, 2 ohms per ch.
Stereo, 4 ohms per ch.
Stereo, 8 ohms per ch. 750W
550W
350W 1,250W
800W
500W
120 VAC, 60 Hz Units, Bridge mono mode
1 kHz with 0.1% THD
4 ohms 1,500W 2,500W
Performance K1 K2
Frequency Response (at 1 watt, 20 Hz - 20 kHz) ± 0.25 dB ± 0.25 dB
Signal to Noise Ratio below rated power (20 Hz to 20 kHz) > 100 dB > 100 dB
Damping Factor: 10 Hz to 400 Hz > 3000 > 3000
Crosstalk (below rated power, 20 Hz to 1 kHz) > 60 dB > 60 dB
Controlled Slew Rate > 13 volts/ms > 13 volts/ms
Input Impedance nominally balanced, nominally unbalanced 20 k ohms, 10 k ohms 20 k ohms, 10 k ohms
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
2-8 ohms
4 ohms
2-8 ohms
4 ohms
Voltage Gain (at maximum level setting)
1.4V sensitivity
26 dB gain
31.5 dB
26 dB
33.1 dB
26 dB
Required AC Mains 50/60 Hz, 100-250 VAC (+10%, -15%) 50/60 Hz, 100-250 VAC (+10%, -15%)
7 Specifications
