7
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
01
04 08
09
05
06 07
02 03
automatiC ClimatE Controls
01
auto Button/DrivEr’s siDE tEmPEraturE Control Dial
The auto mode may be used year-round. Press the auto button to turn the system on
and the system will automatically control the inside temperature (automatic cooling and/or
dehumidified heating), air flow distribution and fan speed.
Turn the driver’s side temperature control dial left for cooler air or right for warmer air.
02
Dual Button/PassEnGEr’s siDE tEmPEraturE Control Dial
Press the passenger’s side Dual control button to turn the passenger’s side temperature
controls on or off. This will allow the passenger’s side temperature to be adjusted
independently from the driver’s side by turning the passenger’s side control.
Turn the passenger’s side temperature control dial left for cooler air or right for
warmer air.
03
fan sPEED Control Buttons
Press the fan speed control buttons to manually adjust the fan speed faster or
slower .
04
DEfrostinG/DEfoGGinG front anD siDE WinDoWs
Press the front window defroster button
to turn the system on. The A/c automatically
turns on when the defroster mode is selected. This feature removes humidity from the air.
use the temperature control dial 01
to set the desired temperature.
To set the defroster on high, press the fan speed control button to increase the fan
speed to the maximum setting.
05
moDE Button
Press the moDE button 05
to cycle through the following air flow outlets:
Air flows from the center and side vents.
Air flows from the center, side, and foot vents.
Air flows mainly from the foot vents.
Air flows from the defroster and foot vents.
06
rEar WinDoW anD outsiDE mirror (if so equipped) DEfrostEr sWitCh
Push the rear window defroster switch to turn the system on or off.
The rear window defroster automatically turns off after approximately 15 minutes.
