FORD 2002 E-450 v.2 - Manual (Page 165)

Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
23 20A Cigar lighter, Data Link Connector
(DLC)
24 — Not used
25 10A Left headlamp (low beam)
26 — Not used
27 5A Radio
28 20A Power plug
29 — Not used
30 15A Headlamps (high beam indicator),
DRL10A
31 10A Right Headlamp (Low Beam),
DRL
32 5A Power mirrors
33 20A E-Traveler power point #2
34 10A Transmission Range (TR) sensor
35 30A RKE module
36 5A (Cluster, A/C, Illumination,
Radio), Steering column assembly
37 20A Rear power point
38 10A Air bag diagnostic monitor
39 20A E-Traveler power point #1
40 30A Modified vehicle
41 30A Modified vehicle
42 — Not used
43 20A C.B. Power windows*
44 — Not used
* Either Fuse 21 or Circuit breaker 43 will be present for power
windows.
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
