Fuel gauge

Displays approximately how much
fuel is in the fuel tank. The fuel
gauge may vary slightly when the
vehicle is in motion or on a grade.

When refueling the vehicle from
empty indication, the amount of fuel
that can be added will be less than the advertised capacity due to the
reserve fuel.

The FUEL DOOR icon and arrow indicates which side of the vehicle the
fuel filler door is located.

Speedometer

Indicates the current vehicle speed.

Odometer

Registers the total kilometers
(miles) of the vehicle.

Trip odometer

Registers the kilometers (miles) of
individual journeys. To reset,
depress the control.

F

E

Instrument Cluster

16
