4x4 w/automatic transmission
Engine Rear axle
ratio
Maximum
GCWR - kg
(lbs.)
Maximum
trailer
weight - kg
(lbs.)
Maximum
frontal area
of trailer -
m 2 (ft 2 )
Regular Cab w/6’ box
3.0L All 6000 (2722) 2300 (1043) 50 (4.64)
4.0L All 9500 (4309) 5720 (2595) 50 (4.64)
Regular Cab w/7’ box
3.0L All 6000 (2722) 2240 (1016) 50 (4.64)
4.0L All 9500 (4309) 5660 (2567) 50 (4.64)
SuperCab
4.0L
(without
FX4
package)
All 9500 (4309) 5560 (2522) 50 (4.64)
4.0L
(with
FX4
package)
All 9500 (4309) 5200 (2359) 50 (4.64)
For high altitude operation, reduce GCW by 2% per 1,000 ft. (300
meters) of elevation.
For definition of terms used in this table, see Vehicle loading earlier
in this chapter.
To determine maximum trailer weight designed for your vehicle, see
Calculating the load your vehicle can carry/tow earlier in this
chapter.
Maximum trailer weight is shown. The combined weight of the
completed towing vehicle (including hitch, passengers and cargo) and
the loaded trailer must not exceed the Gross Combined Weight Rating
(GCWR).
The Ranger is capable of pulling the maximum trailer weight(s) as
specified above. Certain states require electric trailer brakes for trailers
over a specified weight. The Ranger vehicle electrical system is not
equipped to accommodate electric trailer brakes.
