Driving – FORD 2004 Ranger v.3 User Manual
Page 124
4x2 w/manual transmission
Engine
Rear axle
ratio
Maximum
GCWR - lbs.
(kg)
Maximum
trailer
weight - lbs.
(kg)
Maximum
frontal area
of trailer -
ft
2
(m
2
)
For definition of terms used in this table see Vehicle Loading earlier
in this chapter.
To determine maximum trailer weight designed for your particular
vehicle, see Calculating the load your vehicle can carry/tow earlier
in this chapter.
Maximum trailer weight is shown. The combined weight of the
completed towing vehicle (including hitch, passengers and cargo) and
the loaded trailer must not exceed the Gross Combined Weight Rating
(GCWR).
The Ranger is capable of pulling the maximum trailer weight(s) as
specified above. Certain states require electric trailer brakes for trailers
over a specified weight. The Ranger vehicle electrical system is not
equipped to accommodate electric trailer brakes.
4x4 w/manual transmission
Engine
Rear axle
ratio
Maximum
GCWR - kg
(lbs.)
Maximum
trailer
weight - kg
(lbs)
Maximum
frontal area
of trailer -
m
2
(ft
2
)
Regular Cab w/6’ box
3.0L
All
6000 (2722)
2340 (1061)
50 (4.64)
4.0L
All
7000 (3175)
3260 (1479)
50 (4.64)
Regular Cab w/7’ box
3.0L
All
6000 (2722)
2280 (1034)
50 (4.64)
4.0L
All
7000 (3175)
3200 (1451)
50 (4.64)
SuperCab
4.0L
(without
FX4
package)
All
7000 (3175)
3100 (1406)
50 (4.64)
2004 Ranger (ran)
Owners Guide (post-2002-fmt)
USA English (fus)
Driving
124
