4x2 w/manual transmission
Engine Rear axle
ratio
Maximum
GCWR - lbs.
(kg)
Maximum
trailer
weight - lbs.
(kg)
Maximum
frontal area
of trailer -
ft 2 (m 2 )
Regular Cab w/6’ box
2.3L All 4800 (2177) 1580 (717) Equal to
frontal area
of vehicle
3.0L* All 6000 (2722) 2660 (1207) 50 (4.64)
3.0L*
Edge
All 6000 (2722) 2520 (1143) 50 (4.64)
Regular Cab w/7’ box
2.3L All 4800 (2177) 1520 (689) Equal to
frontal area
of vehicle
3.0L* All 6000 (2722) 2580 (1170) 50 (4.64)
SuperCab
2.3L All 4800 (2177) 1420 (644) Equal to
frontal area
of vehicle
3.0L* All 6000 (2722) 2480 (1125) 50 (4.64)
3.0L*
Edge
All 6000 (2722) 2400 (1061) 50 (4.64)
4.0L All 7000 (3175) 3400 (1542) 50 (4.64)
4.0L
Edge
All 7000 (3175) 3320 (1506) 50 (4.64)
For high altitude operation, reduce GCW by 2% per 1,000 ft. (300
meters) elevation.
*When towing on roads with steep grades or moderate but long
sustained grades (5 miles [8 km] or more), or when ambient
temperatures exceed 100° F (37° C), vehicle speed should not exceed
45 mph (72 km/h) in both cases.
