Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
43 — Not used
44 — Not used
45 — Not used
46 — Not used
47 — Not used
48 1 ⁄
2
ISO relay Fog lamps
49 — Not used
50 — Not used
51 1 ⁄
2
ISO relay A/C clutch
52 — Not used
53 1 ⁄
2
ISO relay Fuel pump driver module, Fuel pump
54 — Not used
55 Full ISO relay PCM relay, PDB fuses 40 and 41
56 Full ISO relay Starter motor solenoid
57 Full ISO relay Front A/C blower motor
58 High current
relay
Wipers
59 — Not used
60 1A Diode PCM
61 1A Diode PCM
* Cartridge Fuses ** Mini Fuses
JUMP STARTING YOUR VEHICLE
The gases around the battery can explode if exposed to flames,
sparks, or lit cigarettes. An explosion could result in injury or
vehicle damage.
Batteries contain sulfuric acid which can burn skin, eyes and
clothing, if contacted.
Do not attempt to push-start your vehicle. Automatic
transmissions do not have push-start capability; doing so may
damage the catalytic converter.
REVIEW COPY
2005 Ford Five Hundred (500), Owners Guide (post-2002-fmt) (own2002),
Market: USA_English (fus)
Roadside Emergencies
192
