Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse Panel
Description
F18 10A PCM relay coil, Shifter Brake-Shift
Interlock (BSI), Passive Anti-Theft System
(PATS) module, Fuel relay coil, Brake
lamps, Center High-Mounted Stop Lamp
(CHMSL)
F19 10A Anti-lock Brake System (ABS)/Traction
control module, All Wheel Drive (AWD)
module, RSS, Heated seat modules
F20 7.5A Cluster, Climate control
F21 7.5A Restraint Control Module (RCM)
F22 7.5A Electrochromatic mirror, Compass module
F23 7.5A Wiper relay coil, Blower relay coil, Cluster
logic
F24 7.5A Occupant Classification Sensor (OCS),
Passenger Air bag Deactivation (PAD)
C1 30A Circuit
breaker
Delayed accessory (Front passenger
window, Rear passenger windows [via
window switch], Window switch
illumination, Backlighting
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Always disconnect the battery before servicing high current
fuses.
Always replace the cover to the power distribution box before
reconnecting the battery or refilling fluid reservoirs
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and Specifications chapter.
