If you switch off the AdvanceTrac
௡
with RSC
௡ system, the “sliding car
off” icon will illuminate steadily.
Pressing the AdvanceTrac
௡ with
RSC
௡ button again will turn off the
“sliding car off” icon.
In R (Reverse), ABS and the engine traction control and brake traction
control features will continue to function; however, ESC and RSC
௡ are
disabled.
AdvanceTrac
௡ Features
Button
functions icon
status
RSC
௡
ESC TCS
Default at
start-up
Illuminated
during bulb
check
Enabled Enabled Enabled
Button pressed
momentarily Illuminated
solid
Enabled Enabled Disabled
Button pressed
and held more
than 5 seconds
(speed under
35 mph)
Illuminated
for 5 seconds,
turns off for
3 seconds,
then
illuminated
solid
Disabled Disabled Disabled
Button pressed
and held less
than 5 seconds
(speed over
35 mph)
Illuminated
solid
Enabled Enabled Disabled
Button pressed
again after
deactivation
Not
illuminated
Enabled Enabled Enabled
Transfer case in
4L (4WD Low) Illuminated
solid
Disabled Disabled Disabled
OFF
Driving
171
