Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
38 20A Not used (Spare)
39 20A Radio/Navigation
40 20A Not used (Spare)
41 15A Accessory delay (windows, automatic
dimming rear view mirror [including
microphone and compass] and door
switch III)
42 10A Not used (Spare)
43 10A Heated seat relay coils
44 10A Not used (Spare)
45 5A Wiper relay and module, Blower relay
46 7.5A Not used (Spare)
47 30A Circuit
Breaker
Not used (Spare)
48 — Accessory delay relay (windows,
automatic dimming rear view mirror
[including microphone and compass]
and door switch III)
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Do not probe the contacts for the fuses and relays in the power
distribution box as damage will occur, causing improper, or loss
of, electrical functionality.
WARNING: Always disconnect the battery before servicing high
current fuses.
WARNING: To reduce risk of electrical shock, always replace
the cover to the Power Distribution Box before reconnecting the
battery or refilling fluid reservoirs.
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and Specifications chapter.
2010 05+ Mustang (197)
Owners Guide, 1st Printing
USA (fus)
Roadside Emergencies
223
