196 fuses – FORD 2013 E-450 v.1 User Manual
Page 196
Fuse/relay
location
Fuse amp
rating
Protected components
60
—
One touch integrated start (diode)
61
—
Not used
62
HC micro relay Upfitter #2
63
30A**
Trailer tow battery charge
64
—
Not used
65
20A**
Power point 2 (glove box)
66
20A**
Power point 3 (left B-pillar)
67
20A**
Power point 1 (instrument panel)
68
50A**
Modified vehicle
69
—
Not used
70
30A**
Stripped chassis
71
—
Not used
72
20A**
Cigar lighter / Power point
73
—
Not used
74
30A**
Power seat
75
20A*
Vehicle power 1, Powertrain control
module power
76
20A*
Vehicle power 2, Powertrain control
module – emission related powertrain
components
77
10A*
Vehicle power 3, Powertrain control
module – general powertrain
components
78
15A*
Vehicle power 4, Fuel pump relay coil
79
10A*
Vehicle power 5, Transmission
80
10A*
Cluster run/start (stripped chassis)
81
—
Not used
82
—
Not used
83
—
Fuel pump (diode)
84
—
Not used
85
HC micro relay Upfitter #1
* Mini fuses ** A1S fuses
