CHANGING THE 12V BATTERY
Removing the Battery
WARNINGS
You must replace your vehicle
battery with one of exactly the same
specification.
Make sure the battery box is correctly
sealed.
Your vehicle battery is heavy; take
care when lifting and removing.
Note: If you have power seats and the
battery has no charge, jump-start your
vehicle to move the seat. See Jump
Starting the Vehicle (page 178).
Note: Where applicable you must
reprogram the audio system using the
keycode.
The battery is located inside your vehicle
under the driver's seat.
E152526
1
1. Remove the cover trim by pulling up
the tabs with your fingers.
2
E152529
2. Unhook the cover flap and tuck it under
the seat valance.
E146781
3
4
3. Remove the cover on both sides.
4. Remove the seat runner bolts on both
sides. Slide the seat fully forward,
making sure the arm rest is folded up.
See Seats (page 95).
213
Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014
Maintenance
