Protected components Fuse amp rating Fuse or relay number
Powertrain control module relay. — 82
Not used. — 83
Not used. — 84
Not used. — 85
Not used. — 86
Not used. — 87
Not used. — 88
Electronic fan 1 relay. — 89
Not used. — 90
Electronic fan 3 relay. — 91
Blower motor relay. — 92
Not used. — 93
Fuel pump relay. — 94
*Cartridge fuses.
**Mini fuses.
Passenger Compartment Fuse
Panel
The fuse panel is in the right-hand side of
the passenger footwell behind a trim panel
and plastic key code card.
To remove the trim panel, lift it from the
rear retaining hooks, while pulling it toward
you and swinging it away from the side. To
reinstall it, line up the tabs with the grooves
on the panel, drop the panel back into
place, and then push it shut.
To reach the fuse panel, first remove the
key code card.
After replacing a fuse, return the key code
card to the original position. To reinstall
the trim panel, lineup the tabs with the
grooves on the panel, drop the panel back
into place, and then push it shut to reinstall
the trim panel.
