Protected components Fuse amp rating Fuse or relay number
Latch relay coil. 10A*** 32
Left-hand high-intensity discharge head-
lamps. 20A*** 33
Not used. — 34
Right-hand high-intensity discharge head-
lamps. 20A 35
Alt sense. 10A*** 36
Not used. — 37
Vehicle power 1. 20A*** 38
Not used. — 39
Vehicle power 2. 20A*** 40
Fuel injectors. 15A*** 41
Vehicle power 3. 15A*** 42
Not used. — 43
Vehicle power 4. 15A*** 44
Not used. — 45
Not used. — 46
Not used. — 47
Not used. — 48
Fuel pump. 30A** 49
Steering column lock relay. — 50
Not used. — 51
Horn relay. — 52
Cigar lighter. 20A** 53
Auxiliary power point. 20A** 54
Electronic fan 2. 25A** 55
Not used. — 56
Air conditioning clutch relay. — 57
