Maintenance – FORD 2015 Focus User Manual
Page 228
E133713
4
4. Disconnect the electrical connector.
Replacing the Brake, Rear and
Direction Indicator Bulbs
A
B
E133714
Brake and rear lamp bulb.
A.
Direction indicator bulb.
B.
1.
Remove the bulb holder.
2. Gently press the bulb into the bulb
holder, turn it counter-clockwise and
remove it.
Replacing Rear Lamps - 5 Door
Accessing the Rear, Brake, Side Marker,
Direction Indicator and Reverse Bulbs
E133111
1.
Remove the trim panel.
E133112
2
2. Remove the wing nuts and detach the
clip.
3. Remove the lamp.
225
Focus (CDH), enUSA, First Printing
Maintenance
