FASS T D08 260G User Manual
Page 12
D.
Secure PFB-2002 and RS-2001 with bed bolt in previous step.
B.
For fitting purposes. Secure PBR-2001 to pump assembly lightly with (3) 1/4”-20x1 3/4 bolts and (3)
WA-1001D. This will assembly will be used in future steps for correct fitting of brackets. (Note:
Bracket maybe flipped to accommodate your application.)
C.
Unbolt driver side front bed bolt from bed retain bolt for future use. Align RS-2001 with PFB-2002.
.
E.
Connect factory plug into the FASS harness. Connect female plug of the FASS harness into pump.
Turn key to “on”. With pump operating (you may have to bump the starter), turn pump over, liberally
spray WD-40 (or equivalent) into water separator nipple lubricating Gerotor.
