5
Questions? Call toll free: 1-800-693-1138
Installation Steps
Step 2 - Make Hole For Filtered Water Faucet
Step 3 - Install Faucet
IMPORTANT: To avoid damaging the sink, consult a qualified plumber or installer for drilling procedures
in porcelain or stainless steel. Special drill bits are made for this.
1. Select one of the following places to install the faucet. Be sure there's room underneath so you can
make the needed connections.
• In an existing sink spray attachment hole.
• Drill a hole in the sink top.
• Drill a hole in the countertop next to the sink.
2. If drilling is needed make a 1-1/4" dia. (minimum) hole for the faucet.
1. Feed the 3/8" tubing that is attached to the faucet through the mounting hole. Slide the toggle bolts
through the mounting hole. Tighten the screws to secure the base flat on the mounting surface. Do not
overtighten.
2. Move the faucet down onto the base. Turn 1/4 clockwise to attach the faucet to the base.
3. Install battery in base. See “Battery Change” section for instructions.
Fig. 3
faucet base
1/4 turn to connect
faucet to base
screw
toggle bolt
rubber washer
hole in sink
or countertop
faucet
