Technical specifications, Installing the software – Compaq iPaq HNE-200 User Manual
Page 8
I
NSTALLATION
AND
S
ETUP
G
UIDE
8
I
PAQ N
ETWORKING
10/100 F
AST
E
THERNET
USB A
DAPTER
3. Connect one end of the cable to the RJ-45 port on the USB
Adapter 3 and the other end to any available station port on
a network hub or switch.
Note: When inserting an RJ-45 plug, be sure the tab on the plug clicks into
position to ensure that it is properly seated.
4. Install the product software, including printer sharing, file
sharing and Internet connection sharing, using the Install
Software option on this CD.
Installing the Software
:KHQ \RX DUH ILQLVKHG LQVWDOOLQJ WKH GULYHUV DQG KDUGZDUH \RX
DUH QRZ UHDG\ WR LQVWDOO WKH L3$4 1HWZRUNLQJ VRIWZDUH 3OHDVH
UHIHU WR WKH
6RIWZDUH 'RFXPHQWDWLRQ
RQ WKLV &'
Technical Specifications
Model
HNE-200
Ports
1 USB Type-B
RJ-45 for 10BASE-T/100BASE-TX
Standards
Conformance
IEEE 802.3x for Auto Negotiation,
IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX,
USB Spec v 1.0 and 1.1
Certifications
FCC Part 15B, CE
Access Protocol
CSMA/CD
Driver Support
Microsoft
Windows
98, 98SE, Millennium, 2000
Cable Wiring
(USB port and
RJ-45 port)
90T shielded USB cable, maximum length 5 meters
(16 feet)
10BASE-T: 100T Category 3,4,5 shielded/unshielded
twisted-pair, max length 100 m (328 ft)
100BASE-TX: 100W Category 5 shielded/unshielded
twisted-pair, max length 100 m (328 ft)
Access Method
USB port
USB Spec v. 1.0 and 1.1 differential and
bi-directional, 12 Mbps (high-speed device)
Access Method
RJ-45 port
IEEE 802.3x, IEEE 802.3 and IEEE 802.3u CSMA/CD,
10 and 100Mbps baseband, Full/Half Duplex
Input Power
4.75~5.25 VDC, 0.3A max. (Bus powered from USB
host controller or hub or switch)
Power
Consumption
1.5 Watts maximum (from USB host)
Heat Dissipation
9 BTU/hr
