I NSTALLATION AND S ETUP G UIDE 5 I PAQ N ETWORKING 10/100 F AST E THERNET USB A DAPTER
What’s in Front?
7KH /(' LQGLFDWRUV RQ WKH IURQW SDQHO RI \RXU (WKHUQHW 86%
$GDSWHU KHOS \RX PRQLWRU V\VWHP VWDWXV
What’s In Back?
7KH SRUWV RQ WKH EDFN SDQHO RI \RXU (WKHUQHW 86% $GDSWHU KHOS
\RX PDNH FRQQHFWLRQV WR \RXU 3& DQG WKH QHWZRUN
LED Status Description
1 Power On (green)
Off
Indicates a valid USB power connection.
Indicates there is no power to the
Ethernet USB Adapter.
2 Link/Act On (green)
Flashing
green
Indicates the Ethernet USB Adapter has a
valid network connection.
Indicates data is being transmitted.
3 100 On (amber)
Off
Indicates the Ethernet USB Adapter is
connected to a 100Base-TX network
Indicates the Ethernet USB Adapter is
connected to a 10Base-T network.
Port Description
1 The RJ-45 port is where you connect your USB Adapter to a hub,
switch, or router. You must purchase a twisted-pair cable separately
for this connection.
2 The USB port is where you connect your USB Adapter to your PC. Use
the USB cable provided in the package contents.
