PARTS
DR
®
SNOW THROWER Safety, Operation & Maintenance Instructions 21
Introduction
All parts are illustrated in “exploded views” which show the individual parts in their normal
relationship to each other. Reference numbers are used in the illustrations. These numbers correspond
to those in the “Reference Number” (REF) column, and are followed by the description and quantity
required.
O/L - “Obtain Locally” in the part number column indicates common hardware that is available at your
local hardware supply.
All reference to right and left, forward or rearward, are from the operator steering the DR
®
ALL-
TERRAIN
™
MOWER.
The manufacturer reserves the rights to change, modify, or eliminate from time to time, for technical
or other reasons, certain or all data, specifications, or the product or products themselves, without any
liability or obligation.
