Previous test screen – Humboldt H-3185SD CONTROLLER User Manual
Page 8
H-3185SD
C
ONTROLLER
O
PERATING
I
NSTRUCTIONS
© 2007 Humboldt Manufacturing
8
C
ONTROLLER
S
CREENS AND
N
AVIGATION
(C
ONTINUED
)
Previous Test Screen
Table
The previous test screen will allow you to view all the test data from a
previously run test. Only 10 points can be viewed at a time, you can use the
more and previous button in the tabulation view the next 10 points of the
tabulated data.
Graph
Press the Graph button to view graph of tabulated data. The graph will be
generated automatically and will be a single graph of all the cycles. Press the
Table button to get back to the table view.
Export
Press the Export button to export the data to Windows Hyper Terminal or
Humboldt IR Download. If using Humboldt IR Download please refer to the
IR Download instructions for Exporting data.
COM Port Settings
Use these settings if exporting to Hyper Terminal or similar program.
Baud Rate: 19200
Data: 8 bit
Parity: None
Stop: 1 bit
Flow: None
