Humboldt H-3185SD CONTROLLER User Manual
Page 5
H-3185SD
C
ONTROLLER
O
PERATING
I
NSTRUCTIONS
© 2007 Humboldt Manufacturing
5
C
ONTROLLER
S
CREENS AND
N
AVIGATION
The next section will cover the controller screens if you need instructions
understanding Navigation, please see Navigation instructions.
Initial Test Screen
This screen is your hub to access other parts of the software. This is the screen
we will begin all screen instructions.
Run Test Screen
This section will describe how to setup/run a test as well as navigation and what
each button does.
From the main screen press the button.
Temperature Range
- Use this to adjust the desired freeze temperature and thaw temperature.
Temperature Hold
- Use this to adjust the desired time to hold the temperature at either of the
temperature boundaries. Time is entered in minutes.
Freeze-Thaw Duration
- Use this to adjust the desired time to freeze or thaw. Time is entered in
minutes.
Number of Cycles
- Set the number of cycles the test will run.
RUN TEST
Temperature
Range
Temperature
Hold
Freeze Thaw
Duration
Number of
Cycles
