MAIN MENU
User’s Manual Page 39
11.8.6 Installation
In this menu there are six sub menus each described below:
11.8.6.1 Store origin
This menu is used to calibrate the systems “ZERO” point for both vertical and horizontal axis.
Before the “Store origin” command is stored it is necessary that the synchronization between
operator panel and electrical box is done properly. The easiest way to do the synchronization is
by turning
the system off with the “Park” command, please see 10.6 Off and park.
Start the system according to
6. STARTING SYSTEM (normal start). Now the position of the
lamp housings should be adjusted to be in level with horizontal plane and in direction straight
forward of the vessel (normally)! Then
“Store origin” is executed and setting is stored.
