User’s Manual
Page 3
CONTENT
WARNINGS AND INFORMATION ...................................................................................... 5
1.
COLORLIGHT SEARCHLIGHT SYSTEM........................................................................... 8
2.
OPERATOR PANEL, OVERVIEW ...................................................................................... 9
3.
DISPLAY SYMBOLS AND MESSAGES .......................................................................... 10
4.
4.1
Ebox alarm relay ...................................................................................................... 11
ACTIONS AFTER INSTALLATION OR POWER FAILURE ............................................. 12
5.
STARTING SYSTEM ........................................................................................................ 13
6.
JOYSTICK FUNCTIONS ................................................................................................... 14
7.
SWITCH ON LIGHT .......................................................................................................... 15
8.
FOCUS ............................................................................................................................. 16
9.
9.1
Type 1, continuous focus (standard) ..................................................................... 16
9.2
Type 2, absolute focus (optional for CL25) ............................................................ 17
QUICK START MENU .................................................................................................. 18
10.
10.1
Fixed positions (optional function) ........................................................................ 18
10.1.1
Go to fixed position ........................................................................................................... 18
10.1.2
Store fixed position............................................................................................................ 19
10.2
Sweep (optional function) ....................................................................................... 20
10.2.1
New Sweep ....................................................................................................................... 20
10.2.2
Modify sweep parameters ................................................................................................. 21
10.3
Surveillance (optional function) ............................................................................. 23
10.3.1
Setting a new surveillance sweep ..................................................................................... 23
10.3.2
Changing surveillance settings ......................................................................................... 25
10.4
Switch ....................................................................................................................... 27
10.5
Synchronized control (optional function from ver. 0.5.0.8) .................................. 28
10.5.1
Set the master control searchlight on/off .......................................................................... 30
10.5.2
Add and remove slaves .................................................................................................... 31
10.6
Off and park ............................................................................................................. 32
MAIN MENU.................................................................................................................. 33
11.
11.1
Off and Park ............................................................................................................. 33
11.2
Switch system .......................................................................................................... 33
11.3
Light Position ........................................................................................................... 33
11.4
Sweep ....................................................................................................................... 33
11.5
Surveillance ............................................................................................................. 33
11.6
Info ............................................................................................................................ 34
11.7
Status ....................................................................................................................... 34
