DISPLAY SYMBOLS AND MESSAGES
User’s Manual
Page 11
This symbol indicates that the bulb has less than 200 hours left of expected
lifetime. This warning can be chosen by the operator to be shown or not. Please
see
for more detailed instruction.
Each bulb has its own symbol showing in the lower left or right corner of the
display.
This symbol indicates that the expected lifetime of the bulb now has expired. The
only way to reset this symbol is by entering the “Usage Stats” menu at the
diagnostic display inside the electrical box. See
Certainly this reset should only be done together with a bulb replacement!
This symbol and a similar symbol indicate the direction of the lamp housing both
for the vertical axis and for the horizontal axis. The arrows in the shown symbol
indicate the elevation angle for the vertical axis according to the horizontal-plane.
For the horizontal symbol and axis these small arrows indicate if the housing is
directed to the left, front, right or back of the centerline.
If the arrows are replaced by question marks then the system needs to be
internally calibrated. This is the normal state after power up after a total power loss
to the system. The easiest way to do the internal calibration is by simply choose
the “Park” in the quick start menu, please see
4.1 Ebox alarm relay
The searchlights electrical and mechanical condition are constantly monitored
and if there is a malfunction in the system this is indicated by icons in the panel
display with clarifying warning messages found in the panels status menu.
The control box also has a relay output that can be connected to the boat
monitoring system; see the wiring diagram for connection details.
The following errors trigger the alarm output.
Message
Fault
Communication error
Transmission issues on the CAN bus
Over current
Overcurrent protection triggered, movement blocked
Over voltage
Overvoltage protection triggered, voltage to searchlight motordriver/s
have exceeded 30Vdc.
Under voltage
Undervoltage protection triggered,
voltage to searchlight
motordriver/s has fallen below 10Vdc
OPWDT (message in box only)
Ethernet communication broken to all panels, see
Fault auto-resets if contact is restored with at least one panel
