2 4100172 Rev C
2. Equipment Set-up and Installation
2.1 Unpacking the Benchmark Plus Microplate
Reader
Prior to opening the box, check for any outer damage. Document any damages, if present.
Place the box upright with the TOP label facing up and open the box. Remove the instrument
from the box in this position only.
Warning! Grasp the instrument firmly under the right and left sides before attempting to lift or
carry the instrument out of the box.
Check the instrument for damaged or broken parts. Document any damages in detail.
Each Benchmark Plus instrument includes the following accessories. Verify that they are present:
• 1 Microplate Manager Software with manual. ( Shipped in a separate box )
• 1 serial cable. ( Shipped in a separate box )
• 1 power cord.
• 1 user manual.
Verify that the serial number on the back of the instrument is the same as that on the outside of
the box.
Located on the under-side of the instrument is a docking bolt that needs to be unscrewed prior to
use (Counter Clockwise). When the docking bolt can not be turned any further, the scan arm will
be free inside the instrument.
The Serial port is located on the back of the instrument. There is one connector, which allows the
user to connect to one serial instrument.
Before switching the power on for the first time, allow the Benchmark Plus to warm to room
temperature for 6 hours after unpacking to prevent any condensation problems.
Plug the included power cord into the main power connector port. Ensure that the instrument is
connected to a main power outlet with a grounded conductor.
2.2 Location of the Instrument
The Benchmark Plus microplate reader is a precise optical measuring instrument. The following
conditions must be met to ensure maximum sensitivity:
• Place the instrument on a flat surface that is free of vibration.
• Do not place the instrument in direct sunlight.
• Make sure that the instrument is being operated in a dust-free environment.
