Baseline Systems WaterTec S100 - Manual (Page 11)

11 WaterTec S100 Manual Aug06 Rev. 1
Troubleshooting for Initial Installation
Problem Cause Solution
Er1 is displayed The S100 cannot communicate with
the biSensor • Check the wiring and connections
to the biSensor
• Make sure the correct valve wire
and common wire are used
• After making repairs follow the
“Verify biSensor Communication”
instructions under Step 1 at the end
of this section
Er2 is displayed The S100 has detected excessive
current while trying to communicate
with the biSensor • Double-check the wiring and
connections to the biSensor
• Make sure the common and
biSensor wires are correctly
connected
• Check for a faulty valve solenoid
• After making repairs follow the
“Verify biSensor Communication”
instructions under Step 1 at the end
of this section
Er3 is displayed
along with
another error There was a problem during the S100
24-hour moisture threshold
calibration • This error is accompanied by one
of the other error codes
• Refer to the other Er# for possible
solutions
Er4 is displayed
(this is a warning
message,
pressing”Sensor
Update”will
clear this)
Unexpected reading during 24-hour
moisture threshold calibration, final
reading was not substantially
different from first
(please refer to
the Er4 code on page 17)
• Follow the instructions under Step
5 at the end of this section
• Make sure no extra water is
applied to the biSensor after
calibration starts or the S100 may
set a non-optimal threshold
Er5 is displayed An interruption of the 24-hour
moisture threshold calibration
occurred due to attempted valve
activation • Check the valve the biSensor is
connected to for proper operation
• After making repairs follow the
instructions under Step 5 at the end
of this section (turn off controller
during 24-hour moisture threshold
calibration)
Er6 is displayed Unexpectedly low reading during 24-
hour moisture threshold calibration • Follow the instructions under Step
5 at the end of this section
Display is blank.
LED’s are off S100 is not receiving 24 VAC • Make sure the 24VAC transformer
is plugged in
• Check that the two 24VAC lines
and the common from the S100 are
wired correctly
Display flashes
random
segments or 88.8 The S100 common is not connected
correctly • Make sure the common from the
S100 is connected to the valve
common of the sprinkler controller
