Baseline Systems X-Series Pedestal User Manual
Baseline x-series pedestal installation guide, Materials and tools, X-series pedestal

Materials and Tools
Tools as needed for constructing the concrete form (drill, screwdriver, marker, tape measure, level,
etc.)
2” x 6” lumber for constructing the concrete form
Concrete
Tools as needed for finishing the concrete
Tools as needed for working with conduit (cutter, etc.)
Hardware for the electrical power and irrigation wiring (½” conduit, wire, wire nuts, etc.) and tools as
needed
4 stainless steel anchor bolts with washers and nuts
Wrench for attaching the nuts to the anchor bolts
Baseline X-Series Pedestal
Installation Guide
1-866-294-5847
Rev 3.8.2013
www.baselinesystems.com
X-Series Pedestal
The X-series pedestal units are designed to be mounted on a concrete pad and hold a Baseline
controller in an X cabinet.
Remove all packaging materials from the pieces.
Remove the door from the pedestal.
Identify all parts.
X Cabinet
Pedestal
Pedestal Base
Controller Mounting Bracket
Document Outline
- X-Series Pedestal
- The X-series pedestal units are designed to be mounted on a concrete pad and hold a Baseline controller in an X cabinet.
- Mount the Pedestal Base to the Concrete Pad
- Mount the Pedestal to the Base
- Position the pedestal over the base and lower it into place, making sure that the holes for the screws are aligned.
- Insert the 6 screws and securely tighten the nuts.
- Attach the Controller Mounting Bracket to the Pedestal
- Align the tabs on the controller mounting bracket with the slots in the top of the pedestal, and then slide the mounting bracket into place.
- Insert the 5 screws and securely tighten the nuts.
- Thread the small screw into the hole at the top of the mounting bracket and tighten it part way.
- Mount the Controller to the Pedestal
