SPECIFICATION
PHYSICAL PARAMETERS
Constuction
High impact ABS plastic
Window
Acrylic
Display
Back-lit Liquid Crystal Display:
Large Digits: 28.6mm 1.12"
Small Digits: 11.5mm 0.45"
Dimensions
110 x 110 x 25.4mm 4 x 4 x 1"
Requires 65mm 2.6" depth behind
bulkhead
for
display
barrel
Weight
0.3 kg 0.66lbs
ENVIRONMENTAL
Operating Temp -10 to +55
0
C @ 93%RH
+14
to
+131
0
F @ 93%RH
Storage Temp -25 to +70
0
C @ 95%RH
-13
to
+158
0
F @ 93%RH
Humidity
Up to 95%RH
Sealing
Fully sealed front, suitable for bulkhead
cockpit mounting. Vented barrel to prevent
condensation.
ELECTRICAL
Power Supply
12V DC nominal (10 to 16V)
Operating Current
40mA typical, 100mA illuminated
Protection
Connect via external fuse or
circuit
breaker.
CABLES AND CONNECTIONS
Connection to adjacent units is via cable tails fitted with either
a plug or a socket. Extension cables are available from your
dealer. The cable tails carry power and NMEA data between
units.
ALARM
Internal audible alarm
NMEA OUTPUT SENTENCES
$IIHDM Heading
$IIVHW
Speed and Heading
$IIDBT Depth
$IIVWR
Apparent wind angle and speed
$IIMTW Sea
temperature
