c. Check the size of the intake piping is still suitable at the new equivalent length. Should there be
any discrepancies, re-estimate the next larger size and replicate the steps above. The line
may also be sized more precisely by conducting an actual calculation. Intake piping must be
sized to induce no more than 4inches water column vacuum at the compressor when all
compressors are operating. (Use total capacity for this calculation with all compressors running).
For unusual lengths or other circumstances, please contact your Local Amico Source representative for
assistance.
5. Finalize the connection to the distribution piping and size the system piping.
6.3.8 Specification
1. Select the sections appropriate to the technology and system layout desired.
2. Note into the specification any exceptional requirements (soft starters, etc.) that are necessary.
3. Schedule on the drawings the medical air plant selected.
Schedule at least:
a. The capacity per compressor and total system capacity.
b. kW per compressor and Horsepower.
c. Voltage, Hz, and phase desired.
6.3.9 Technology Comparison Chart
Amico Source offers several technologies for medical air, each of which has its own advantages and drawbacks. This
page summarizes these as an aid in the selection of the correct technology for your specific application.
Characteristics Scrolls Reciprocating
Size • 10 HP • 10 HP
dBa@10 HP • 73 • 84
LPM@828 kPa • 798 L/Min • 985 L/Min
Advantages • Compact and light • Customizable
weight configuration
• Reliable • Extremely reliable
• Low noise level • Best efficiency CFM/hp
(Very quiet and vibration free)
• Easy to maintain
Format • Modular Stacking • Modular Stacking
• Horizontal Tank Mount • Horizontal Tank Mount
• Skid Mount • Skid Mount
Maximum Pressure • 862 kPa (125 psig) • 827 kPa (120 psig)
SCFM@ 120psig • 28.2 SCFM • 34.8 SCFM
Disadvantages • Less convenient when • Louder than scroll
servicing large capacities
