Amico Monitor Roll Stands - Manual (Page 10)

9 Amico Accessories Inc.
WARNING: DO NOT tighten one screw all the way in the clamp device without the other. Only tighten the first
screw after the second screw is at least half way into the clamp assembly or the clamp maybe damaged. (Figure 7)
WARNING: Ensure the clamp device is the correct side up. The rounded edge of the clamp faces up while the more
squared edge faces down. The finished side of the handle faces up. (Figure 8)
1. Place the clamp device at the desired height on the Roll Stand post.
2. Line up the holes up on the handle with the holes on the clamp device. Start one of the two HEX bolts BUT DO
NOT TIGHTEN, then start the second bolt. Once both bolts are started, tighten the bolts. (Figure 9)
Roll Stand Post
Clamp Device
3/16’’ Hex Bolt
Roll Stand Handle
Figure 9
Handle Installation
Figure 8
UP (more rounded edges)
DOWN (more squared edges)
INCORRECT CORRECT
Clamp
Assembly
Roll Stand
Post
Clamp Assembly
on Clamp
Figure 7
