Great Plains Mfg., Inc.
8 Grease Bank Kit
151-128M 02/20/2008
Great Plains Manufacturing, Inc.
Corporate Office P.O. Box 5060
Salina, Kansas 67402-5060 USA
Parts Lists
New Parts
This manual covers the installation of two different grease
bank kits. Parts are listed for each kit separately.
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual.
Quantities are units (“ea”) unless otherwise noted. The
kits are “universal” and include enough zerks, adaptors
and tubing for maximum-row-count drills. If your drill has
fewer row units, parts will be left over.
Kit Contents
Existing Part Affected
The following existing part is involved in the kit installa-
tion. The Disposition column indicates whether the part is
left in place, moved or not re-used. The part call-out number in the list matches all Figures in
the installation instructions. The description matches that
in your drill Parts manual.
Abbreviations
151-126A 7’ GREASE BANK KIT 151-127A 10’ GREASE BANK KIT
Callout
Quantity in Kit
Part
Number Part Description
151-126A 151-127A
1 1 151-128M MANUAL 7&10 GREASE BANK KIT
1 2 197-194D GREASE BANK MOUNT
2 4 197-258D GREASE BANK MOUNT PLATE
11 16 800-130C GREASE ZERK STRAIGHT 1/8-27NPT
14 14 800-150C CABLE TIE 22.2 LONG REL.
11 16 800-158C FTG TUBE,CONNECTOR 1/8 FNPT
11 16 800-211C GREASE ADAPT 1/4-28M X 1/4 TB
4 8 802-004C HHCS 1/4-20X3/4 GR5
4 8 803-006C NUT HEX 1/4-20 PLT
4 8 804-006C WASHER LOCK SPRING 1/4 PLT
4 8 804-007C WASHER FLAT 1/4 SAE PLT
50 ft 75 ft 990-109R TUBE NYLON 1/4OD X 062WL
11
12
13
14
15
16
17
18
19
20
21
22
Callout Part No. Part Description Part Disposition
800-001C GREASE ZERK STRAIGHT 1/4-28 Removed and not re-used.
FTG Fitting OD Outside Diameter
HEX Hexagonal (6-sided) PLT Plated
HHCS Hex Head Cap Screw (Bolt) SAE Society of Automotive Engineers (standards)
NPT (Female/Male) National Pipe Thread WL Working Length
51
