Marker tank, Figure 5 marker tank, Handrail – Great Plains TSF1260 Predelivery Manual User Manual
Page 11: Figure 6 handrail in transport, Figure 7 handrail in operation
Assembly 9
11/09/2006
500-642Q
Marker Tank
19. Mount the marker tank on the right side of the
sprayer.
Handrail
20. Cut plastic tie securing handrail to sight gauge
weldment. Remove handrail.
Refer to Figure 5
21. Attach handrail to left-hand walkboard.
Figure 5
Marker Tank
23243
Figure 6
Handrail in Transport
24349
Figure 7
Handrail in Operation
24349
