32 TS750 and TS1000 Trailer Sprayer 500-104M 4/8/03
Great Plains Mfg., Inc.
TS750 and TS1000
Specifications
* If tractor cannot restrict flow to 6 gpm, purchase a flow-control kit from your Great Plains dealer.
† At 24 inches behind lower lift-arm balls.
Wheel Spacing Tandem 80"-120"
Single Axle 80"-120"(TS1000P) / 72"-120"(TS750P)
Tires: Standard Optional Tandem 12.5L x 15"
Single Axle 13.6 x 28 R1, 13.6 x 38 R1
Transport Width 12’8" (60’ Boom)
Height 12’2" (60’ Boom)
Length 225" (60’ Boom)
Control Options Manual Electric or Raven 440 Monitor
Constant Pressure Boom Plumbing STD with Manual Electric Controls
Great Plains Pump Options Hydraulic Drive, Frame Mount 540/1000 RPM
Boom Option CF60, CF50, MF45, MF40, MF30
Boom Elevator 36" Hydraulic Lift
Boom Height Adjustments
Lowest/Highest
15" to 55"
Foam Marker Optional
Pull Through Hitch N/A
Axle Clearance 25" (13.6-28) / 29" (12.4-38 or 13.6-38)
Loaded Weight Approx. 13,130 lbs on TS1000P / 11.055 lbs on TS750P
Hitch Options Ball, Single strap
Bottom Fill Kit Standard
Tractor Requirements
Electrical System 12-volt, negative ground
Hydraulic System For hydraulic pump, one hydraulic remote that can restrict
flow to 6 gpm.*
For hydraulic elevator and hydraulic pump used in combina-
tion, two hydraulic remotes.
Pumps
Tractor mounted PTO pump - 540 RPM
Tractor mounted PTO pump - 1000 RPM 1 3/8” spline
Tractor mounted PTO pump - 1000 RPM 1 3/4” spline
Hydraulic pump
Tractor mounted high volume PTO pump - 540 RPM
Tractor mounted high volume PTO pump - 1000 RPM 1 3/8”
spline
