5

8/21/06

Two-Section, Hydraulic Folding Marker 113-329M

Great Plains Mfg., Inc.

Assembly

Bleeding Marker Hydraulics

1.

Be sure tractor hydraulic reservoir if full.

2.

With the marker(s) unfolded, crack the hydraulic hose fit-

ting(s) at the base end of the cylinder(s). With your tractor at

an idle speed, activate your tractor hydraulic valve until hy-

draulic oil seeps out around the hose ends. Tighten the

hose-end fittings and repeat this process with the hose-end

fitting(s) at the rod end of the cylinder(s). If dual markers are

used with a selector/sequence valve, follow the procedure

above for one marker cylinder. Then crack the fittings on the

back side of the selector/sequence valve, activate the trac-

tor hydraulics valve until hydraulic oil seeps out around the

hose ends. Tighten the hose-end fittings and repeat the

complete process for the opposite marker cylinder.

3.

Fold and unfold the marker(s) slowly to work all the air out of

the hydraulics. Use caution when folding and unfolding the

marker for the first time, and check for pinching and kinking

of hoses.

NOTE: JIC fittings do not require high torque. JIC and O-ring fit-
tings do not require sealant. Always use liquid pipe sealant when
adding or replacing pipe-thread fittings. To avoid possible danger
of cracking hydraulic fittings from over tightening, do not use
plastic sealant tape.
