63 CultiPress
Operating Instructions
7. Parts and Assembly
AS3735 F/W CULTIPRESS DRAWBAR
ASSEMBLY 2011
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00045 BOLT M36x200 GR. 8.8 2
2 P02007 NUT LOCK M12 1
3 P02012 NUT LOCK M36 2
4 P02600 WASHER FLAT M10 4
5 P02609 WASHER FLAT M39 2
6 P03088 BOLT M12x60 GR. 8.8 1
7 P03763 WASHER FLAT M30 4
8 P04126 BUSH SPRUNG - Ø32xØ26x20 4
9 P05492 NUT LOCK 1" UNF 4
10 P05534 NUT LOCK M10 2
11 P05535 WASHER FLAT M8 3
12 P05567 BOLT 1" UNFx5" GR. V 2
13 P08548 BOLT 1" UNFx7" GR. V 2
14 P08802 SHIM KIT 7 PIECE 2
15 P08817 WASHER SPRING M8 3
16 P09092 HOSE STOWAGE PLATE 1
17 P09112 CLAMP ½" BSP PAIR 9
18 P09113 CLAMP - TOP PLATE 3
19 P09252 HOSE MAST 1
20 P09597 BOLT M8x25 GR. 8.8 3
21 P10049 BOLT M8x25 STAUFF STACK 6
22 P10138 HITCH CAT3 - SLOTTED 1
23 P10173 POLYURETHANE BLOCK 1
24 P10174 15mm SHIM 1
25 P10175 5mm SHIM 1
26 P10176 POLYURETHANE BLOCK RETAINER 1
27 P10234 LOCK CLIP 6
28 P10278 BOLT M8x45 GR. 8.8 3
29 P10575 HITCH CAT4 ECONOMY - SLOTTED 1
30 P12690 BOLT M10x30 GR. 8.8 2
31 P17216 CULTIPRESS 2009 F/W DRAWBAR 1
32 P17815 MANUAL HOLDER - COMPLETE 1
