CultiPress

Operating Instructions

18

2.7 Preceding & Trailing

Implements

Adding a preceding or trailing

implement to the CultiPress will

affect the stability and handling

of the machine both in transport
and work.

2.7.1 Hitching a Disc Cultivator

to the CultiPress

1. Remove the transport straps from the

disc cultivator, exercise great CARE

when extending the axle cylinder.

2. Reverse the disc cultivator up to the

CultiPress drawbar ensuring that the

two drawbars are aligned allowing

a slight clearance to enable the

machines to be coupled together.

3. Lower the disc cultivator to the ground.

4. Connect the four hydraulic hoses from

the CultiPress into the disc cultivator

rear outlets ensuring that the two

wing hoses are together and the two

drawbar cylinder hoses are together.

Ensure that the folding circuits and lift

drawbar circuits are coupled correctly.

5. Raise the CultiPress drawbar above

the disc drawbar (200mm approx.).

Depth control shims may need to be

removed.

2. Transportation / Installation

2.6 Air Brake Coupling

Procedure

Please refer to the following procedure

when coupling or decoupling any item of

Simba Great Plains machinery fitted with an

AIR brake or AIR and HYDRAULIC brake

system. Please note that this procedure

does not apply to any machines fitted with

a HYDRAULIC system ONLY.

2.6.1 When Coupling

1. Reverse up to the machine and

connect the machine to the tractor as

instructed to in Section 2.4.1.

2. With the machine connected couple

the air lines. When coupling ensure the

yellow line is attached first followed by

the red line.

3. Your brake hoses are now attached

and are ready for operation.

4. Continue with the coupling process as

instructed in Section 2.4.1.

2.6.2 When De-coupling

1. Bring the machine to the parking

position as instructed to in Section 2.9.

2. With the machine still connected to

the tractor remove the red brake line

followed by the yellow line.

3. Your brakes will now be ON and will

hold, ensuring they have been adjusted

and maintained correctly, the machine

in position. (note: if the machine‘s tank

is drained of air once all lines have

been detached the brakes will come off

(same situation as pushing the shunt

valve).

4. Continue de-coupling the machine until

it is fully disconnected.

By following the above instructions

you will see that at NO point

in the coupling or decoupling

process has the red line been

left in the tractor on its own.

This is intentional and should be

considered the ‘rule’ to coupling

the hoses.
