141 CultiPress
Operating Instructions
7. Parts and Assembly
AS1784 CULTIPRESS
5.5m LH WING ASSEMBLY PROACTIVE
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00003 BOLT M12x40 GR. 8.8 20
2 P02008 NUT LOCK M16 'TYPE T' 12
3 P02009 NUT LOCK M20 2
4 P02037 WASHER SPRING M12 20
5 P02601 WASHER FLAT M12 20
6 P02602 WASHER FLAT M16 12
7 P02603 WASHER FLAT M20 6
8 P03115 BOLT M20x60 GR. 8.8 2
9 P05208 ROLL PIN ؼx1 5/8" 2
10 P06802 BOLT U M16 GR8.8 190x117 6
11 P07744 TIE STRAP SHORT 1
12 P07745 TIE STRAP - LONG 1
13 P07746 WING FOLD STRAP PIN 1
14 P07916 BUSH SPRUNG - Ø32xØ26x25 4
15 P09112 CLAMP ½" BSP PAIR 2
16 P09113 CLAMP - TOP PLATE 2
17 P09558 SCRAPER PLATE 6
18 P09559 SCRAPER STEM RH 3
19 P09560 SCRAPER STEM LH 3
20 P10029 SCRAPER 1 1/2 4
21 P10278 BOLT M8x45 GR. 8.8 2
22 P13062 WING UNIT LH 5.5m PRO ACTIVE 1
